Special custom series

YH-50

International Size Rating

Injection Unit

Screw specification

A

B

C

D

Screw diameter

mm

23

25

27

/

Screw ratio

L/D

20

20

20

/

Theoretical injection capacity

cm³

50

59

69

/

Injection weight

g

45

53

62

/

Injection rate

g/s

78.7

93.0

108.5

/

Injection pressure

Mpa

243

206

177

/

Screw rotation speed

r/min

0-250

Clamping Unit

Auxiliary machine specifications

Clamping force

KN

500

Dryer

12-25kg

Mold opening stroke

mm

330

Feeder

300g

Space between tie bars

mm

330×370

Air switch specification

A

Max.Mold Height

mm

350

Power cord specification

mm²

Min.Mold Height

mm

100

Mold positioning ring specification (mm)

Ø50mm

Ejector Stroke

mm

70

Nozzle aperture (mm)

Ø

Ejector Force

KN

23.9

Nozzle spherical R angle

SR

Others

Mold clamping screw specification

M12

Oil pump motor power

KW

7.9

Template outline dimension (mm)

Heater power

KW

4.95

Foundation bearing requirement

Machine dimension

M

3.18×0.93×1.64

Oil cooler water flow requirement (L/min)

Machine weight

T

2.2

Cooler inlet and outlet pipe interface

Hopper capacity

L

17

Minimum mold size (length × width) (mm)

Oil Tank Capacity

L

110

Instructions:

1. Theoretical injection volume = cross-sectional area of the injection molding machine's barrel × injection stroke

2. Actual injection volume = theoretical injection volume × 0.91 (calculated based on GPPS)
